Description
What’s in the box:
- Olympus DS-9000 Professional Digital Dictaphone
- Olympus LI-92B Lithium-ion Rechargeable Battery
- Olympus KP30 Micro USB Cable
- Olympus CS-151 Carry Case
- Olympus AS-9001 ODMS (Olympus Dictation Management System) Release 7 (for Windows)/DSS Player for Mac dictation software license
Optional Accessories
- OM System ODMS Cloud – 12-month subscription
- Olympus CR21 Docking Station
- Olympus F-5AC for Audio AC Adapter
- Olympus RS-31H Footswitch for Hands Free Dictation
- Olympus ME33 Boundary Microphone
- Olympus ME34 Compact Zoom Microphone
- Olympus ME30W Omni Directional 2 Channel Microphone Kit
- Olympus ME15 Tie Clip Microphone
- Olympus TP8 Telephone Pickup Microphone
- Olympus AS-9002 – ODMS (Olympus Dictation Management System) Release 7 (for Windows)/DSS Player for Mac transcription software licence
- Olympus AS-9000 Professional Digital Transcription Kit
- Phlips SpeechLive 12-month subscription – cloud solution
Specifications
Display | |
Display type | Full Colour TFT LCD with white LED backlight |
Display size | 36.72mm x 48.96mm / 2.4 inch (240 x 320 pixels) |
Memory | |
Internal memory | 2GB |
External memory | up to 32GB SD |
Storage media | SD, SDHC |
Device Operation | |
Main switch | Precise slide switch (REC / STOP / PLAY / REW) |
Power switch | Yes (ON/OFF) |
Programmable button | 3 programmable smart buttons |
Power Supply | |
Requirements | Rechargeable Lithium-ion battery (1350mAh) |
External power supply | A517 or F-5AC AC Adapter (supplied) |
Battery | LI-92B |
Battery life | Recording (QP mode): Approx. 9.5 hours |
Internal battery charge | AC / USB / Cradle (all using Olympus rechargeable battery only) |
Recording | |
Built-in microphone | Intelligent Two Microphone System |
Microphone type | Electret condenser | 8Ø x 2 |
Directional characteristic | Dictation1 (Omni-Directional mono), Dictation2 (Narrow), Conference (Digital Directional stereo) |
Microphone sensitivity | 3 Level (High/Middle/Low), (Conference Mode = Auto) |
Recording format | DSS / DSS Pro / WAV / MP3 |
Voice activated recording | VCVA |
Hands-free recording | Dictation & Transcription via optional Footswitch RS-31H |
Level meter | Yes |
Playback | |
Playback speed control | Slow / Normal / Fast |
Cue / review | Yes |
Editing & Workflow | |
Partial erase | with DSS / DSS Pro |
File erase | Erase all files/ Erase single files |
Insert | with DSS / DSS Pro / WAV |
Overwrite | with DSS / DSS Pro / WAV |
Append | with DSS / DSS Pro / WAV |
Index mark | 32 per file (DSS Pro/WAV/MP3), 16 per file (DSS) |
Author ID setting | 10 |
Work type ID setting | 20 |
Priority setting | Yes (High / Normal) |
Verbal comments | up to 32 per file |
Folders | Up to 7 (name changeable), 200 files per folder |
Text editor | Yes |
Pending | Yes |
Additional Functions | |
Wireless features | No |
Security | |
Device lock by PIN | Yes |
File encryption / decryption | DSS Pro real time encryption (128 / 256 bit) |
Lock single files | Yes |
General | |
Housing colour | Black |
Dimensions | 120.8mm (H) x 49.8mm (W) x 18.6mm (D) |
Weight | 116.5g (including battery) |
Microphone jack | Ø3.5mm mini jack | impedance 2kΩ |
EAR jack | Ø3.5mm mini jack | impedance 8Ω or more |
Speaker | Built-in 11 x 15mm square dynamic speaker |
Maximum speaker output | 320mW (8Ω speaker) |
Compatible OS | Windows 7,8.1,10,
Mac OS 10.10 – 10.13 |
Compatible software | Olympus Dictation Management System (ODMS) R7 / DSS Player for Mac V7 |
Docking station | CR-21 (supplied), CR-15 (optional) |
Supplied items | LI-92B Lithium-ion rechargeable battery, A-517 AC Adaptor, KP-30 microUSB Cable, CS-151 Carrying Case, CR-21 Docking Station, Olympus Dictation Management System (ODMS) License (Dictation Module) |
Languages | EN / DE / CZ / DK / ES / FR / NL / PL / RU / SV/ IT |
